ECS GF7050VT-M5 User Manual

38
Introducing the Motherboard
CMOS Setup Utility - Copyright (C) 1985-2007, American Megatrends, Inc.
Smart Fan Function
Help Item
Smart Fan Function
f
Scroll to this item and press <Enter> to view the following screen:
Disabled
Enabled
Options
SMART Fan Control Disabled
SMART Fan Control (Disabled)
This item allows you to enable or disable the control of the system fan speed by
changing the fan voltage.
Shutdown Temperature (Disabled)
This item nables you to set the maximum temperature the system can reach before
powering down.
System Component Characteristics
These items display the monitoring of the overall inboard hardware health events,
such as System & CPU temperature, CPU & DIMM voltage, CPU & system fan
speed,...etc.
• CPU Fan Speed
• CPU Temperature
• System Temperature
• VDIMM
• CPU Vcore
Press <Esc> to return to the main menu setting page.
F10: Save ESC: Exit+/-/: Value
Enter : Select
F9: Optimized Defaults
F1:General Help
: Move
mnlk
Press <Esc> to return to the PC Health Status page.

ECS GF7050VT-M5 Specifications

General

Number of memory slots	2
Maximum internal memory	8 GB
Processor socket	LGA 775 (Socket T)
Processor manufacturer	Intel
Compatible processor series	Intel Core 2 Duo, Intel Core 2 Quad
CPU fan connector	Yes
Number of SATA connectors	4
Serial ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Certification	ROHS
Power source type	ATX
Audio output channels	6.1 channels
Motherboard form factor	micro ATX
BIOS type	AMI
BIOS memory size	64 Mbit
Maximum graphics card memory	256 MB
RAID levels	0, 1

Weight and Dimensions

Depth	194 mm
Width	244 mm
