ECS H110M-C3D User Manual

Chapter 1
6
H110M-C3V/H110M-C3D USER MANUAL
Table of Motherboard Components
LABEL COMPONENTS
1. CPU Socket
LGA1151 socket for Intel
®
Sk
y
lake
p
rocessor
2. CPU_FAN 4-pin CPU cooling fan connector
3. IDEA_MEMORY IDEA Memory jumper
4. DIMM1~2 240-pin DDR3L Module slots
5. ATX_POWER Standard 24-pin ATX power connector
6. SATA1~4 Serial ATA 6Gb/s connectors
7. F_PANEL Front panel switch/LED header
8. TPM Trusted platform module header
9. ME_UNLOCK ME unlock header
10. F_USB1~2 Front panel USB 2.0 headers
11. COM Onboard serial port header
12. F_AUDIO Front panel audio header
13. CASE CASE open header
14. BZ Buzzer header
15. PCIEX1 PCI Express Gen2 x1 slot
16. USB3F Front panel USB 3.0 header
17. PCIEX16 PCI Express x16 slot Gen3 for graphics interface
18. SYS_FAN 4-pin system cooling fan connector
19. CLR_CMOS Clear CMOS jumper
20. ATX_12V 4-pin +12V power connector

ECS H110M-C3D Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR3L-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1600, 1866, 2133 MHz
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
DirectX version	12.0
USB 2.0 connectors	2
Number of SATA III connectors	4
Number of Parallel ATA connectors	-
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Supported storage drive interfaces	SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
BIOS type	AMI
BIOS memory size	64 Mbit
Certification	CE/FCC, ErP/EuP, WHQL, WHCK
Component for	PC
Motherboard chipset	Intel® H110
Audio output channels	- channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Bundled software	CyberLink Media Suite, eBLU, eDLU, eSF
LAN controller	Realtek RTL8111H

Weight and Dimensions

Depth	170 mm
Width	225 mm
