64
H110M-C3V/H110M-C3D USER MANUAL
Chapter 4
If the auto-install DVD-ROM does not work on your system, you can still install
drivers through the file manager for your OS (for example, Windows Explorer). Look
for the chipset and motherboard model, and then browse to the directory and path
to begin installing the drivers. Most drivers have a setup program (SETUP.EXE) that
automatically detects your operating system before installation. Other drivers have
the setup program located in the operating system subfolder.
Manual Installation
ECS Utility Software (Intelligent EZ Utility)
ECS Intelligent EZ Utility provides friendly interfaces under Windows O.S, which makes
your computing more easily and conveniently.
If the driver you want to install does not have a setup program, browse to the
operating system subfolder and locate the readme text file (README.TXT or
README.DOC) for information on installing the driver or software for your operating
system.
These software(s) are subject to change at anytime without prior notice. Please
refer to the support disk for available software.
Windows 7/8 will appear below UAC (User Account Control) message after
the system restart. You must select “Yes” to install the next driver. Continue
this process to complete the drivers installation.

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ECS H110M-C3D and is the answer not in the manual?

ECS H110M-C3D Specifications

General IconGeneral
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Supported memory typesDDR3L-SDRAM
Maximum internal memory32 GB
Supported memory clock speeds1600, 1866, 2133 MHz
Processor socketLGA 1151 (Socket H4)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Pentium
Maximum number of SMP processors1
DirectX version12.0
USB 2.0 connectors2
Number of SATA III connectors4
Number of Parallel ATA connectors-
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
Supported storage drive interfacesSATA III
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
BIOS typeAMI
BIOS memory size64 Mbit
CertificationCE/FCC, ErP/EuP, WHQL, WHCK
Component forPC
Motherboard chipsetIntel® H110
Audio output channels- channels
Motherboard form factormicro ATX
Windows operating systems supportedWindows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Bundled softwareCyberLink Media Suite, eBLU, eDLU, eSF
LAN controllerRealtek RTL8111H
Weight and Dimensions IconWeight and Dimensions
Depth170 mm
Width225 mm
