Chapter 2
24
H110M-C3V/H110M-C3D USER MANUAL
No. Components No. Components
1CPU_FAN4 BZ
2 ATX_POWER 5 SYS_FAN
3 F_PANEL 6 ATX12V
After you have installed the motherboard into a case, you can begin connecting the
motherboard components. Refer to the following:
2-4-7. Connecting Case Components
