ECS H110M-C3D User Manual

Chapter 3
H110M-C3V/H110M-C3D USER MANUAL
58
Main Advanced Chipset Tweak Security Boot Exit
+/- : Change Opt.
Enter/Dbl Click : Select


: Select Screen
/Click: Select Item
F1: General Help
F2: Previous Values
F3: Optimized Defaults
F4: Save & Exit
ESC/Right Click: Exit
This page enables you to set the keyboard NumLock state.
Boot Menu
Operation System Select (Windows 7 or other OS)
This item is used to select the operation system.
Launch PXE OpROM (Disabled)
The item enables or disables launch PXE Option ROM.
Launch Storage OpROM (Enabled)
Use this item to enable or disable the Storage OpROM.
Fast Boot (Disabled)
This item enables or disables boot with initialization of a minimal set of device
required to launch active boot option. Has no effect for BBS boot options.
Bootup NumLock State (On)
This item enables you to select NumLock state.
Quiet Boot (Enabled)
This item enables or disables quiet boot.
Update System BIOS (Enabled)
This item enables or disables update system BIOS.
Boot mode select (LEGACY)
Use this item to select boot mode.
Boot Option #1 /
2 /3 /4 /5 /6 /7 /8
These items show the boot priorities.
Windows 7 or other OS:
Boot policy for Legacy OS.
Windows 8: Boot policy for
UEFI OS without
Compatibility Support
Module(CSM).
Manual: User customized
CSM parameters & boot
policy.
Boot Configuration
Operation System select Windows 7 or other OS
Launch PXE OpROM Disabled
Launch Strorage OpROM Enabled
Fast Boot Disabled
Bootup NumLock State On
Quiet Boot Enabled
Update System BIOS Disabled
Boot mode select LEGACY
FIXED BOOT ORDER Priorities
Boot Option #1 Hard Disk
Boot Option #2 CD/DVD
Boot Option #3 USB Hard Disk
Boot Option #4 USB CD/DVD
Boot Option #5 USB Key: Silicon-Pow...
Boot Option #6 USB Floppy
Boot Option #7 USB Lan
Boot Option #8 Network
USB Flash Drive Priorities
USB Flash Drive Priorities
This item enables you to specify the sequence of loading the operating system. Press
<Enter> to see the submenu.

ECS H110M-C3D Specifications

General

Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR3L-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1600, 1866, 2133 MHz
Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
DirectX version	12.0
USB 2.0 connectors	2
Number of SATA III connectors	4
Number of Parallel ATA connectors	-
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
Supported storage drive interfaces	SATA III
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
BIOS type	AMI
BIOS memory size	64 Mbit
Certification	CE/FCC, ErP/EuP, WHQL, WHCK
Component for	PC
Motherboard chipset	Intel® H110
Audio output channels	- channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64
Bundled software	CyberLink Media Suite, eBLU, eDLU, eSF
LAN controller	Realtek RTL8111H

Weight and Dimensions

Depth	170 mm
Width	225 mm
