Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Measurements and Reports
- 110 -
No.
Measurement
Group
Measurement
Item
Description
Method
LVIDd
Left Ventricular Internal Diameter at
End-diastole
LVIDs
Left Ventricular Internal Diameter at
End-systole
LVPWd
Left Ventricular Posterior Wall
Thickness at End-diastole
LVPWs
Left Ventricular Posterior Wall
Thickness at End-systole
1.7
AO
AoD
Aortic Root Diameter
Ao Asc
Ascending Aorta Diameter
Desc Ao Diam
Descending Aorta Diameter
1.8
Dimensions
RVOT Diam
Right Ventricular Outflow Tract
Diameter
LVOT Diam
Left Ventricular Outflow Tract
Diameter
MV Diam
Mitral Valve Diameter
MVA
Mitral Valve Area
Ellipse in
B-mode generic
measurements
AVA
Aortic Valve Area
MPA Diam
Main Pulmonary Valve Diameter
Distance in
B-mode generic
measurements
PV Diam
Pulmonary Valve Diameter
TV Diam
Tricuspid Valve Diameter
IVC Diam
Inferior Vena Cava Diameter
RVDs
Right Ventricular Diameter at
End-systole
1.9
LA/RA
RA Length
Right Atrium Length Diameter
Distance in
B-mode generic
measurements
RA Width
Right Atrium Width Diameter
LA Length
Left Atrium Length Diameter
LA Width
Left Atrium Width Diameter
LA Dimen
Left Atrium Dimension
2.0
PISA
MR Rad
Mitral Valve Stenosis Radius
PISA (See
