Acclarix AX8/Acclarix AX7 Diagnostic Ultrasound System User Manual Utilities
- 151 -
11.1.3. Store/Print Set-up
Figure 11-3 Store/Print Set-up Screen
Item
Options
Description
Store1/Store2/
Alt Store
Store Image
Store static image to internal hard disk
Store Clip
Store clip to internal hard disk
SONY-UP-D25MD,
SONY-UP-D898MD_X898MD
Connect the corresponding printer to print
the current image.
Store Clip to USB
Store clip directly to USB disk.
Store Image to USB
Store static image directly to USB disk.
Compression
Lossless/Low/Medium/High
Set the image compression type
Duration
≤10 seconds
Set the clip capture duration
Target Frame
Rate
5/10/15/20/25 Hz
Set the clip capture frame rate
Report Printer
Printers
List up to six printer models that have been
added to this system recently. If one of the
six printers is connected to the system
again, you can print directly.
Add
Add a new printer to this system, and its
printer model will be shown in printers list.
Test
Test whether the printer is connected
successfully.
Clear
Clear all the printer settings.
Table 11-3 Store/Print Set-up Description
