Patient Monitor User Manual Calculation and Titration Table
- 201 -
Items English Full Name/Description
SVR Systemic vascular resistance
SVRI Systemic vascular resistance index
PVR Pulmonary vascular resistance
PVRI Pulmonary vascular resistance index
LCW Left cardiac work
LCWI Left cardiac work index
RCW Right cardiac work
RCWI Right cardiac work index
LVSW Left ventricular stroke work
LVSWI Left ventricular stroke work index
RVSW Right ventricular stroke work
RVSWI Right ventricular stroke work index
EF Ejection fraction
25.3 Oxygenation Calculation
25.3.1 Calculation Procedure
1. Select Menu > Common Function > Calculation > Oxygenation.
2.
Manually enter the values required on this interface. You can also directly obtain the values
of patient height, patient weight, C.O. and FiO
2
if they are available from the monitor by
selecting
Get Info.
3.
Select Calculate to output parameter value.
25.3.2 Input Parameters
Items English Full Name/Description
C.O.
Cardiac output
FiO
2
Percentage fraction of inspired oxygen
PaO
2
Partial pressure of oxygen in the arteries
PaCO
2
Partial pressure of carbon dioxide in the arteries
SaO
2
Arterial oxygen saturation
PvO
2
Partial pressure of oxygen in venous blood
SvO
2
Venous oxygen saturation
Hb Hemoglobin
CaO
2
Arterial oxygen content
