Patient Monitor User Manual Recording
- 207 -
Recording Type Description/ Procedure
12-lead analysis recording Select ECG Setup > 12-L Review, click Record to start
recording.
C.O. measurement recording Select C.O. Option > C.O. Measure, click Record to start
recording.
Frozen waveform recording In the Freeze window, click Record to start recording.
To manually stop recording, click Record again in the related windows.
The recorder will automatically stop recording in the following situations:
The recording task is finished.
No paper in the recorder.
Malfunction stops the recorder from running properly.
NOTE:
You can also use the button on the front panel or select shortcut key to
manually start or stop recording.
26.3 Recorder Operations and Status Messages
26.3.1 Record Paper Requirement
Only standard thermosensitive record paper can be used: otherwise the recorder may not function,
the recording quality may be poor, and the thermosensitive print head may be damaged.
26.3.2 Proper Operation
■ When the recorder is working, the record paper goes out steadily. Do not pull the paper
outward with force: otherwise the recorder may be damaged.
■
Do not operate the recorder without record paper.
26.3.3 Paper Out
When the Recorder Out OF Paper alarm is displayed, the recorder cannot start. Please insert
record paper properly.
26.3.4 Replacing Paper
1. Pull outwards the upper arc part of the recorder casing to release the casing, shown in the
following figure.
