EDAN elite V5 - Spo 2

Patient Monitor User Manual Product Specifications
- 256 -
Adult/Pediatric 130 s
Adult/Pediatric (Sports Mode) 120 s
Neonate 75 s
Overpressure protection
Adult/Pediatric < 300 mmHg
Neonate < 150 mmHg
Pre-inflation Pressure
Adult Mode Default: 160 mmHg
Range:120/140/150/160/180/200/220/240/260/280
mmHg
Pediatric Mode Default: 140 mmHg
Range:
80/100/120/140/150/160/180/200/220/250 mmHg
Neonatal Mode Default: 90 mmHg
Range: 60/70/80/90/100/120/140 mmHg
A.14 SpO
2
Complies with ISO 80601-2-61: 2011.
EDAN Module
Measuring Range 0% to 100%
Resolution 1%
☆Data Update Period
1 s
☆Accuracy
☆Adult /Pediatric
±
2% (70% to 100% SpO
2
)
Undefined (0% to 69% SpO
2
)
☆Neonate
±
3% (70% to 100% SpO
2
)
Undefined (0% to 69% SpO
2
)
Sensor
Red Light
(660
±
3) nm
Infrared Light
(905
±
10) nm
Emitted Light Energy <15 mW
