Patient Monitor User Manual Monitoring ECG/ RESP
- 119 -
HOLD HI and HOLD LO are unavailable, and the monitor can calculate the respiration rate
automatically. When it is set to MANUAL mode, you can adjust the broken lines in RESP
area by the HOLD HI and HOLD LO items.
HOLD HI/LO: when the HOLD TYPE is MANUAL, you can adjust the broken lines for
higher or lower limit of the respiration rate.
DEFAULT: pick this item to access the RESP DEFAULT CONFIG dialog box, in which
the user may select whether the FACTORY DEFAULT CONFIG or the USER
DEFAULT CONFIG is to be used. After selecting any of the items and exiting the dialog
box, the system will pop up the dialog box asking for the user’s confirmation.
Figure 13-18 RESP Default Configuration
WARNING
The respiration sensitivity will descend after using the defibrillation cable, and the “4”
mode is recommended in the WAVE AMP.
