Edge-Core AS6701-32X - Figure 2: Rear Panel

Chapter 1 | Switch Description
System Overview
– 11 –
Figure 2: Rear Panel
Fan Trays: The switch includes five hot-swappable fan trays for system cooling.
Power Supply Units: The switch supports dual hot-swappable AC power supply
units (PSUs). You can install up to two PSUs with matching airflow direction in the
switch.
Grounding Terminal: The switch supports a single-screw grounding terminal. The
grounding terminal must be connected to a ground source that provides local
earth potential.
3
2
1
4
5
6
7
8
Power Supply Unit 1 Fan Tray 3
Power Supply Unit 2 Fan Tray 4
Fan Tray 1 Fan Tray 5
Fan Tray 2 Grounding Terminal
1
5
2
6
3
7
4
8
