4 Power and Grounding
This chapter focuses on how to connect AC power to the switch, grounding the
chassis, and how to power-on the switch.
This chapter includes this sections:
◆ “Switch Power Supply” on page 28
◆ “Grounding the Chassis” on page 29
◆ “How to Connect to AC Power” on page 30
Switch Power Supply
The switch requires power from an external AC power supply that can meet the
required specification described in Table 2. A standard AC power socket is located
on the rear panel of the switch. The power socket is for the AC power cord.
Figure 14: AC Power Supply Socket
Plug the AC power cord into the socket on the rear of the switch.
