– 8 –
Tables
Table 1: Key Technical Specifications 13
Table 2: AC Power Supply Specifications 29
Table 3: Port Status LEDs 34
Table 4: Maximum Twisted-Pair Copper Cable Lengths 36
Table 5: 10/100BASE-TX MDI and MDI-X Port Pinouts 37
Table 6: 1000BASE-T MDI and MDI-X Port Pinouts 38
Table 7: ECS2100 Series PoE Power Budget 39
Table 8: Maximum Gigabit Ethernet Fiber Cable Lengths 40
Table 9: System Status LEDs 43
Table 10: Console Cable Wiring 44
Table 11: Troubleshooting Chart 47
