– 15 –
2 Installation Overview
This chapter includes these sections:
◆ “Package Contents” on page 15
◆ “Switch Installation Tasks” on page 16
Package Contents
After unpacking the switch, check the contents to be sure you have received all the
components.
◆ ECS2100-10T, ECS2100-10P, ECS2100-10PE, ECS2100-28T, ECS2100-28P or
ECS2100-28PP Web-Smart Pro Gigabit Ethernet Switch
◆ AC Power Cord—either US, Continental Europe or UK
◆ Rack Mounting Kit containing two standard brackets and eight screws for
attaching the brackets to the switch.
◆ 4 adhesive foot pads
◆ Quick Start Guide
◆ Regulatory and Safety Information
Optional Item
◆ Console cable—RJ-45 to DB-9
Note:
For other documentations include Installation Guide, Web Management
Guide, and CLI Reference Guide can be obtained from www.edge-core.com ->
support -> download -> user manual.
