7 Installation
Equipment required:
 Terminal Block & Terminal Cover Screws:
 Terminal Flat blade (5mm x 0.8mm) thickness
OR
 PZ/PH 2 with torque setting
Consumables:
 Three screws with specifications stated below:
 Threaded section ≤ 5mm in diameter
 Screw head ≥ 8mm in diameter
The following table provides an overview of the installation process.
Step 1
Step 1: Unpack meter and inspect for damage
Step 2
Step 2: Remove terminal cover from meter. See page 14.
Step 3
. See page 14.
Step 4
Step 3: Isolate mains power supply
Isolate the mains power supply according to your company’s safety standards.
Step 4: Remove old meter. See page 15.
Step 5
Step 5: Mount the meter to the install point. See page 15.
Step 6
Step 6: Connect supply wires to the meter’s terminal block. See page 16.
Step 7
Step 7: Replace terminal cover and fit the Communications Hub. See page 17.
Step 8
Step 8: Turn on the mains power supply. See page 17.
