EDMI ES-12B - Meter Dimensions; Figure 2-1: Meter Dimensions

ES-12B 5 Terminal Single Phase Residential Electricity
Meter - Installation and Commissioning Guide
Copyright © 2020 EDMI Europe Ltd. All rights reserved
Version / Status: 1.0
Public
PAGE 8 OF 25
2 Meter Dimensions
`
Note: Height, width and depth values for the meter do not include the dimensions of the
Communications Hub. Please refer to the relevant Product Guide for Communications Hub
dimensions.
Figure 2-1: Meter Dimensions
