EDWARDS SYSTEMS TECHNOLOGY CMDN - Phase 2 - Parameter Entry for Selected Display

28 CMDN Manual
Annunciator Network Parameters
Parameter FCC/DCPU
Class A
FCC/DCPU
Class B
IRC-3 (FCC/PCPU)
(Class A or B)
Selected Display Y Y N
Selected Base Address N N Y
Fault Action Y Y N
PC Comm Port Y Y Y
(Annunciator) Network Comm Class Y Y N
Communications Baud rate Y Y Y
Q(Number of addresses) N N Y
Select Base Address N N Y
* In order to enter any value greater than 1 for the Selected Display,
you MUST first define the Number of Displays that will be used. Then,
you may Select any Display within the range of 1 up to the Number of
Displays which you defined.
Note: In the IRC-3 mode, the annunciator will automatically configure
to Class A operation when connected to a Class A data line.
IRC-3(FCC/PCPU) and FCC/DCPU Phase 2 - Parameter
Entry for Selected Display (Individual Annunciator
Configuration)
After the network parameters have been entered, each CMDN/SMDN
must be configured (phase 2). Press
Tab to advance to the “Parameter
Entry for Selected Display” menu.
WED FEB 6, 1994 11:16:35 Remote Alpha-Numeric Display Network
PARAMETER ENTRY for SELECTED DISPLAY
Current Project File: Base Address: 5 IRC-3
Project Name: Printer:
Location: Baud Rate:
Active When Enabled:
Active When Disabled:
L Enter Location P Select Printer
E Select Active when Keyswitch Enabled B Select Printer Baud Rate
D Select Active when Keyswitch Disabled T Transmit to Display N
Set to No Switch Panel H Print to Hard Copy (or File)
INSTRUCTIONS
Press Press letters L, E, D, P, or B to alter the corresponding item.
Press letters N, T, H, or F to execute the action stated.
Press TAB to move to the next screen and enter or edit messages.
The selection shown above will be saved.
Press ESC to return to prior menu - selection shown will be saved.
IRC-3 Selected Display Menu
