CMDN Manual 29
WED FEB 6, 1994 11:16:35 Remote Alpha-Numeric Display Network
PARAMETER ENTRY for SELECTED DISPLAY
Current Project File: Select Display: 1 FCC
Project Name: (Comm - No Printer Available)
Location: Baud Rate: 9600
Annunciation Type(s): Alarm + Supervisory + Trouble Routing: All Messages
Routing: All Messages
Active When Enabled:
Active When Disabled: FCC Text: OFF
L Enter Location C Select FCC Text P Select Printer
A Select Annunciation Type(s) B Select Comm Baud Rate
E Select Active When Keyswitch Enabled R Select Routing of Mess
D Select Active when Keyswitch Disabled T Transmit to Display
N Set to No Switch Panel H Print Hard Copy (or File)
INSTRUCTIONS
Press letters R, A, C, L, E, D, or B to alter the corresponding item.
Press letters N, T, or H to execute the action stated.
Press TAB to move to the next screen and enter or edit messages.
The Selections shown Above will be saved.
Press ESC to return to prior menu-Selections shown will be saved.
FCC Selected Display Menu
Verify that the address of the first display to be configured appears in
the Base Address window for IRC-3 operations or the Selected Display
window for FCC operation. If not, return to the previous screen by
pressing ESC, then moving the cursor to the Base Address or Selected
Display window by pressing S and use the Up or Down arrow keys
until the desired address appears in the window. When the desired
address appears in the “Base Address” or "Selected Display" Window
press TAB to save the network configuration and return to the
"Parameter Entry for Selected Display" screen.
Note: All information displayed on this screen applies to the CMDN/
SMDN whose address is displayed in the Base Address or
Selected Display window.
The Parameter Entry for Selected Display screen is the first of two
screens used to configure each CMDN/SMDN (phase 2), and enter its
messages (phase 3).
Enter the required annunciator information for the parameters listed
below. Detailed parameter specifications may be found in the
Parameter Descriptions and Specifications section.
Location
Annunciation Type (FCC only)
Active when Key switch Enabled
Active when Key switch Disabled
No Switch Panel
Printer (Not available on first and last address display panels
on FCC)
Communications Baud Rate (when local printer attached)
Routing (FCC only)
FCC Text (FCC Only)
Note: The data for multiple IRC-3 mode annunciators may be saved
under the same filename, as long as each annunciator has a different
network address.
