Edwards E2M80 User Manual

A344-02-880 Issue J
Page 8 © Edwards Limited 2007. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
2.3 Mechanical data
2.4 Electrical data: single-phase motor
When you start a cold pump, the motor draws the start-up current shown in Table 1 for less than one second. To
prevent unnecessary fuse failure during start-up use a slow-blow fuse. Within five minutes, as the oil in the pump
warms up, the start-up current reduces to the full-load current specified in Table 1.
2.5 Electrical data: three-phase motors
Refer to the data in Table 2. You can configure the dual voltage motors to operate with either the high range or low
range electrical supply: refer to the diagram specified in Table 2. Dual voltage motors are supplied preset to the
highest of the selectable voltages.
When you start a cold pump, the motor draws the start-up current listed in Table 2 for less than one second. Within
five minutes, as the oil in the pump warms up, the current drawn slowly reduces to the full-load current specified in
Table 2.
When you restart a hot pump, the motor draws the start-up current specified in Table 2 for up to 0.5 seconds. The
current drawn then immediately falls to the full-load current value.
Dimensions See Figure 2 (E1M40 and E2M40 pumps) and Figure 3 (E1M80 and
E2M80 pumps)
Degree of protection (IEC 34-5:1981) IP55
Pump inlet-port ISO40 or NW40
Pump outlet-port 25 mm flange, suitable for NW25 fittings
E1M40 E2M40 E1M80 E2M80
Maximum mass (kg) 70.5 72 95 105
Noise level at 1 metre (dB(A)) 65 65 70 70
Table 1 - E lect r ical data (si n gle- p hase moto r)
Pump
Nominal
supply
(V)
Frequency
(Hz)
Power
(kW)
Full-load
current
(A)
Start-up
current
(A)
Recom-
mended
fuse rating
(A)
Electrical
Supply
Connection
Figure
E1M40
E2M40
240 50 1.1 6.8 40 25 4
