A344-02-880 Issue J
Page 44 © Edwards Limited 2007. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Spares and accessories
7.4.11 Vibration isolators
Use vibration isolators (see Figure 12, item 6) to reduce vibration and noise when the pump is floor or
frame-mounted. You must use flexible bellows or other flexible piping between inlet and outlet connections when
you fit vibration isolators.
Figure 12 - Accessories
Product Item Number
Vibration Isolators (set of 4) A248-01-405
1
2
3
4
6
5
AA/5010/A
7
1. Inlet dust-filter or inlet catchpot or inlet chemical trap or high capacity inlet dust-filter
2. Solenoid-operated gas-ballast valve
3. External oil-filter (15-litre capacity)
4. External oil-filter (6-litre capacity)
5. Outlet catchpot or outlet mist-filter
6. Vibration isolator
7. Oil level monitor
