Edwards E2M80 User Manual

© Edwards Limited 2007. All rights reserved. Page 9
Edwards and the Edwards logo are trademarks of Edwards Limited.
Technical data
A344-02-880 Issue J
2.6 Lubrication data
Note: An Edwards Health and Safety Data Sheet for the following oil is available on request.
Table 2 - E l ectr i cal d ata ( thre e -pha s e mo t ors)
Pump
Nominal
supply
(V)
Frequency
(Hz)
Power
(kW)
Full load
current
(A)
Start-up
current
(A)
Recom-
mended fuse
rating
(A)*
Electrical
supply
connection,
Figure
E1M40
or
E2M40
220-240 50 1.1 4.5 25 15 5
380-415 50 1.1 2.6 14 10 6
E1M80
or
E2M80
220-240 50 2.2 8.5 51 30 5
380-415 50 2.2 4.9 29 20 6
E1M40
or
E2M40
208 50 1.5 6.8 41 25 5
208-230 60 1.5 6.5 39 25 5
460 60 1.5 3.1 18.6 15 6
E1M80
or
E2M80
208 50 3.0 12.4 71 40 5
208-230 60 3.0 11.8 71 40 5
460 60 3.0 5.6 34 20 6
*You may need to use a different fuse rating. Use the information supplied with your circuit breaker or starter
to select the correct fuse rating.
Recommended oil* Ultragrade 70
E1M40 E2M40 E1M80 E2M80
Oil capacity (litres)
Maximum 4.6 4.07 7.0 6.3
Minimum 2.2 2.2 4.0 4.0
*To operate your pump when the ambient temperature is outside the limits specified in Section 2.1, or to
optimise your pump performance when you pump condensable vapours, you may need to use a different oil.
