A344-02-880 Issue J
Page 12 © Edwards Limited 2007. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Installation
3.3 Unpack and inspect
z Remove all packing materials, remove the pump from its packing-box, remove the protective covers from the
inlet and outlet-ports and inspect the pump.
z If the pump is damaged, notify your supplier and the carrier in writing within three days; state the Item
Number of the pump together with your order number and your supplier's invoice number.
z Retain all the packing materials for inspection.
z Do not use the pump if it is damaged.
Check that your package contains the following items:
If the pump is not to be used immediately, replace the protective covers. Store the pump in suitable conditions, as
described in Section 6.1.
WARNING
Use suitable lifting equipment to move the pump. The mass of the pump is between 70.5 kg and
105 kg.
Table 3 - C heck l ist
Qty. Description Check (3)
1E1M/E2M40 or 80 Rotary Vacuum Pump
Inlet fitting packs, containing:
2ISO40 Co-seal halves
1NW40 Co-seal half (aluminium)
1ISO40/NW40 seal (nitrile)
1'C clamp
2 M8 x 25 hexagon head bolts
2Washers
Outlet fitting pack, containing:
1'C clamp
1Tube adaptor
1Centering ring NW25
1'O' ring
2Fixing screws, M8 x 20mm
2Fixing washers, M8 shakeproof
