A344-02-880 Issue J
Page 42 © Edwards Limited 2007. All rights reserved.
Edwards and the Edwards logo are trademarks of Edwards Limited.
Spares and accessories
7.4.6 Outlet mist-filter (clean applications)
The outlet mist-filter (see Figure 12, item 5) collects the oil contained in the oil-mist forming part of the discharge
gases. You can monitor the level of oil trapped in the filter, through a sight-glass. This mist-filter must only be used
for clean applications, for other applications see Section 7.4.7. You can return the trapped oil to your pump using
the oil return kit. The mist-filter is supplied with two N W25 'C clamps, NW25 elbow, two N W25 centring rings and
'O' rings, bolts, washers, mounting bracket and studs.
7.4.7 Outlet mist-filter (toxic applications)
The outlet mist-filter (see Figure 12, item 5) collects the oil contained in the discharge gases. You can monitor the
level of contaminants through a sight-glass. You must check that the specification of the mist-filter you choose is
suitable for your application. The mist filter is supplied with two NW25 'C clamps, NW25 elbow, two NW25 centring
rings and 'O' rings, bolts, washers, mounting bracket and studs.
7.4.8 External oil filter
The external oil filter (see Figure 12, item 3 or 4) is a free-standing filter. You can choose between two types of
oil-filter. The 'A' series uses an activated earth cartridge which provides chemical cleaning of the oil by removing
acidic and other aggressive contaminants. The 'M' series uses a pleated paper cartridge which does not provide
chemical filtering but removes abrasive particles down to 0.5 microns. The series 'A' and series 'M' oil-filters are
available in two sizes; the EOF100 has a 6-litre capacity, the EOF300 has a 15-litre capacity. You must check that the
external oil filter you choose is suitable for your application.
Product Item Number
MF100 Mist Filter A462-03-000
Clean Application Oil Return Kit A500-04-000
Product Item Number
MF100AE Mist Filter A462-11-000
Product Item Number
EOF100A External Oil Filter A500-24-000
Activated Earth Element for EOF100A A223-04-043
EOF300A External Oil Filter A500-03-000
Activated Earth Element for EOF300A A223-04-033
EOF100M External Oil Filter A500-25-000
Mechanical Filter Element for EOF100M A223-04-044
EOF300M External Oil Filter A500-23-000
Mechanical Filter Element for EOF300M A223-04-042
EOF100A and M Connection Kit A500-39-000
EOF300A and M Connection Kit A364-01-020
