© Edwards Limited 2007. All rights reserved. Page 49
Edwards and the Edwards logo are trademarks of Edwards Limited.
Appendix A
A344-02-880 Issue J
A3 Installation
A3.1 Pump external fittings, connections and controls
You should familiarise yourself with the external fitting points, connections and controls on the pump. See Figures A1
and A2.
Figure A1 - External oil-filtration unit tapping points
1
2
AA/5011/A
1. External oil-filtration pipe outlet-connection
2. External oil-filtration pipe inlet-connection
