Cause Check that the red light is not on or ashing.
Remedy If LED is on, check the red alarm LED symptoms.
Fault Fail signal or standby signal not working
Cause The serial enable line is not acve.
R
emedy Must be disconnected or driven high for use of standby and fail lines.
Cause Slide switch is not in the correct posion for R
S232 or RS485.
Remedy Le for RS485, right for RS232.
Right for parallel control and monitoring.
Fault Yellow service LED is ashing a repeated sequence
Cause A service is necessary.
Remedy Refer to Flashing servic
e codes on page 85.
Fault The red alarm LED is on
Cause The red alarm LED is on is normal during the soware upgrade process.
At other mes, if the red alarm LED is on it shows a problem is detected in the
FLASH memory.
Remedy If soware is upgrading, complete the upgrade process.
If the red alarm LED is on at other mes:
▪ restart the system
▪ upgrade the soware (if restarng the system does not correct the fault) .
Fault The red alarm LED is ashing
Cause A fail c
ondion has acv
ated.
Remedy Note the posion of the long ashes in the series of 6 ashes to nd the error
code.
Refer to Flashing error codes on page 88 and obey the instrucons.
Fault Other problems
Cause Fault condions other than pr
eviously menoned.
Remedy Contact us or the supplier.
8.1 Flashing service codes
When a service is necessary, the standard once per revoluon ash on the yellow status
LED is changed to a service ash code. Refer to Table: Flashing service codes for the
service ash codes.
04/2022 - ©Edwards Limited
Page 85B80000880_G
B80000880_G - Fault nding
