E F A P O W E R E V - PC - I N S T A L L A T I O N A N D U S E R M A N U A L
6 | 37
ETL marked units and GB marked units have the same appearance but with a difference on the output power
rating:
EFAPOWER EV-PC for USA market (aka Level 2) has 2 plug outputs of up to 7,2kVA.
EFAPOWER EV-PC for China market can be configured with 2 plug outputs from 3,7kVA up to 22kVA.
Figure 4 - EFAPOWER EV-PC Plug Station Parts
Output connection
Wall Mount
Central Unit
Optional
Pedestal
Optional
Pedestal with
door
Fixing to the floor
Mount
Power rating
indication
TFT color
Output
signaling
RFID
