Note: All stainless steel valve parts are passivated.
Specifications and technical details are subject to
engineering changes without prior notification.
VALVEMATE
™
7040 Controller
Cabinet size: W 7.5" x D 5.6" x H 2.7"
(W 19 x D 14 x H 7 cm)
Net weight: 3.1 lb (1.4 kg)
Air input required: 70 psi (4.8 bar) minimum
Input voltage: 100/120/220 VAC selectable
Power required: 50/60 Hz 14/12VA
Foot pedal voltage: 5 VDC
Time range: .001 to 99.9 seconds
Timing control: Microprocessor-based CMOS logic
Time cycle repeat 0.00005 seconds
Time reset: Less than 20 milliseconds
Initiation: Dry contact closure or 5 to 24 VDC signal
Output pressure:
Actuating air 70 psi (4.8 bar)
Nozzle air 1 to 30 psi (0.07 to 2.07 bar)
Cycle rate: Exceeds 600 per minute
Cycle end feedback circuit: N.C. solid-state switch
5 to 24 VDC, 250 mA maximum load
Specifications
780S Spray Valve
Size: 4.120" x 1.060" dia. (104.6 x 26.9 mm)
Weight: 780S: 8.3 oz (235 g)
780S-SS: 14.3 oz (405 g)
Air cylinder body: 780S-SS: Type 303 stainless steel
780S: Hard-coated aluminum
Fluid chamber: 780S-SS: Type 303 stainless steel
780S: Hard-coated aluminum
Piston: Type 303 stainless steel
Piston return spring: Type 303 stainless steel
Needle and Nozzle: Type 303 stainless steel
Air cap: 780S-SS: Type 303 stainless steel
780S: Plated brass
Needle packings: Teflon
®
Packing spring: Stainless steel
Liquid inlet hole: 1/8 NPT female
Mounting: 1/4-28 UNF tapped hole
Operating frequency: Exceeds 400 per minute
Air pressure required: 70 psi (4.8 bar)
Minimum mounting center distance: 1.067" (27.1 mm)
Standard nozzle diameter: 0.046" (1.17 mm)
Optional nozzle sizes: 0.028" (0.71 mm)
0.014" (0.36 mm)
Spray patterns: Round (standard)
Fan (optional)
3 / Specifications
