Effekta MH6000 - Back Panel Overview

UPS MH6000 Manual
MH Series
Page 18 of 51
6.2 Display on the back side
Fig. 3:
back side view
Danger!
All the connections on the back side (except of: RS232-interface, SNMP
adapter) have got circuit potential when attached. Also when uncoupled
dangerous voltage capacity in possible in the inside of the unit.
A
B
C
F
G
H
M
N
E
D
J
I
K
L
