EG4 LiFePower4 - Page 5

3
GENERAL SPECIFICATIONS
PARAMETER
SPEC
TYPE
CONDITION
CELL BALANCE
120mA
Passive
Balance
Cell Voltage Difference >40mV
TEMPERATURE ACCURACY
3%
Cycle
Measurement
Measuring Range
40°F ‒ 212°F
(-40°C ‒ 100°C)
VOLTAGE ACCURACY
0.5%
Cycle
Measurement
For Cells/Module
CURRENT ACCURACY
3%
Cycle
Measurement
Measurement Range
+/-200A
SOC
5% - Integral Calculation
POWER CONSUMPTION
(SLEEP & OFF MODE)
<300uA -
Storage/Transport/
Standby
POWER CONSUMPTION (OPERATING)
<25mA - Charging/Discharging
COMMUNICATION PORTS
RS485/CAN - Customizable
MAXIMUM MODULES IN SERIES
1
MAXIMUM MODULES IN PARALLEL
64
E-STOP FUNCTION
Yes
DIMENSION (H×W×D)
6.1 in. × 19 in. × 17.4 in. (155 mm × 442 mm × 470 mm)
WEIGHT
99.6 lbs. (45.2 kg)
ENVIRONMENTAL PARAMETERS
CHARGING RANGE
32°F – 113°F (0°C – 45°C)
DISCHARGING RANGE
-4°F – 122°F (-20°C – 50°C)
STORAGE RANGE
-4°F – 122°F (-20°C – 50°C)
INGRESS PROTECTION
IP20
STANDARDS AND CERTIFICATIONS
MODULE
UL 1973 ETL Recognized Component Certification
UL9540A (Passed)
UL9540 listed with 18kPV-12LV
*EG4 recommends this value be set no lower than 20% to maintain the recommended 80% depth of discharge.
