USER MANUAL MAGIC 500 PLUS ULTRASOUND UNIT
T +49 7461 96 580 0 | F + 49 7461 96 580 90 | export@eickemeyer.com | www.eickemeyer.com
6.2.6 Grid Setting
1. In real-time mode, press key to enter the main menu, press direction keys to select “Preset”.
2. Press key to enter setting interface.
3. Press direction keys to select “Grid”.
4. Press direction keys to select “00-09”.
“00” shows “no grid”
“01” shows backfat ruler, vertical spacing of ruler is 5mm
“02” shows “line grid”
“03” shows “dot grid”
“04” shows 10mm-spacing dot-like scale
“05” shows 2mm-spacing dot-like scale
“06” show 10mm-spacing and 2mm-spacing dot-like scales
“07” shows longitudinal 1mm-spacing grid (when the image depth is less than 10cm)
“08” shows longitudinal 5mm-spacing grid
“09” shows longitudinal 10mm-spacing grid
5. Press key to confi rm this setting and quit setting interface.
Note: Grid is displayed on B mode after has been set.
6.2.7 WiFi Setting
1. In real-time mode, press key to enter the main menu, press direction keys to select “Preset”.
2. Press key to enter setting interface.
3. Press direction keys to select “WiFi”.
4. Press direction keys to select between “On” and “Off”.
5. Press key to confi rm this setting and quit setting interface.
6.2.8 RF Setting
1. In real-time mode, press key to enter the main menu, press direction keys to select “Preset”.
2. Press key to enter setting interface.
3. Press direction keys to select “RF”.
4. Press direction keys to select RF channels among “1 – 8” or select RF “Off”.
5. Press key to confi rm this setting and quit setting interface.
Note: When setting RF, it costs more time to select the channels.
6.2.9 Background Color Setting
1. In real-time mode, press key to enter the main menu, press direction keys to select “Preset”.
2. Press key to enter setting interface.
3. Press direction keys to select “BackColor”.
4. Press direction keys to select six kinds of background colors.
5. Press key to confi rm this setting and quit setting interface.
6.2.10 User Name Setting
1. In real-time mode, press key to enter the main menu, press direction keys to select “Preset”.
2. Press key to enter setting interface.
3. Press direction keys to select “User Name”.
4. Press key, the cursor is located above “ID”; at the same time characters input menu will be shown at the bottom of the
screen:
Caps 0 1 2 3 4 A B C D E F G H I J K L M
Shift 5 6 7 8 9 N O P Q R S T U V W X Y Z
Press direction keys to move the cursor to point to Caps, and then press key to achieve capital and small letter
conversion; if the cursor points to Shift, press key to achieve the conversion between the letter and punctuation.
