USER MANUAL MAGIC 500 PLUS ULTRASOUND UNIT
T +49 7461 96 580 0 | F + 49 7461 96 580 90 | export@eickemeyer.com | www.eickemeyer.com
7. GENERAL MEASUREMENT
7.1 Distance Measurement
1. In B, B / B mode, freeze the desired image, press direction keys to move the cursor to “Measure” position of display area.
2. Press key, the measurement methods are shown in the lower left of the screen, press direction keys to choose
“1. Distance”, press key again, the cursor will show “+”.
3. Press direction keys to move the “+” mark to desired position, press key to set the “+” mark position as the starting
point of the measurement.
4. Press direction keys to move the “+” mark to the end point of the measurement. A lighted dotted line appears between the
starting point and the end point as the dashed locus of the measurement. The measured value is automatically displayed
at the built-in mark“+: ----mm” on the right side of the screen.
5. Press key to exchange the starting and end point of the measurement.
6. Press key to fi nish the fi rst measurement.
7. Press key again, repeat the steps 3 – 6 to complete the multi-group data measurement.
8. Press key to quit the measurement status.
9. Press direction keys to choose “Clear” and press key to clear all marks and data.
10. Press key to return the real-time status.
7.2 Circumference / Area / Volume Measurement
Circumference / Area / Volume Measurement with Ellipse Method
1. In B, B / B mode, freeze the desired image, press direction keys to move the cursor to “Measure” position of display
area.
2. Press key, the measurement methods are shown in the lower left of the screen, press direction keys to choose
“2. Ellipse”, press key again, the cursor will show “+”.
3. Press direction keys to move the “+” mark to desired position, press key to set the “+” mark position as the starting
point of the measurement.
4. Press direction keys to move the “+” mark to the end point of the measurement, at the same time the elliptic curve
appears.
5. Press key, the “- +” mark appears on the lower right of the image. Hold down or key to change the minor
axis of
the ellipse to satisfy the test area. The measured values are displayed at the built-in characters
“C: ----mm, A: ----mm²,
V: ----cm³” on the right part of the screen automatically.
6. Press key again to quit the minor axis status; Press key to exchange the starting and end point.
7. Press key to fi nish the fi rst measurement.
8. Press key again, repeat the steps 3 – 7 to complete the multi-group data measurement.
9. Press key to quit the measurement status.
10. Press direction keys to choose “Clear” and press key to clear all marks and data.
11. Press key to return the real-time status.
Circumference / Area Measurement with Trace Method
1. In B, B / B mode, freeze the desired image, press direction keys to move the cursor to “Measure” position of display area.
2. Press key, the measurement methods are shown in the lower left of the screen, press direction keys to choose
“3. Trace”, press key again, the cursor will show “+”.
3. Press direction keys to move the “+” mark to desired position, press key to set the “+” mark position as the start of the
measurement.
4. Press direction keys to move the “+” mark to the end point of the measurement. At the same time, a locus appears in the
direction of operation between the two measurement marks. The measured circumference value is displayed automatically
at the built-in mark “C: ----mm” on the right part of the
screen. Press key to display at the built-in mark “A: 0,0mm²”
the value of the measured area formed by measurement
line enclosure.
5. Press key again, repeat the steps 3 – 4 to complete the multi-group data measurement.
