USER MANUAL MAGIC 500 PLUS ULTRASOUND UNIT
T +49 7461 96 580 0 | F + 49 7461 96 580 90 | export@eickemeyer.com | www.eickemeyer.com
6.8 One-key Storage Image
1. In B, B / B, B / M, M mode, freeze the image.
2. Press key, the image code such as “036” is displayed on the lower right corner of the screen. After the code disappears,
the current frozen image is stored in the frame “036”.
Explanation:
1. One-key storage can save the current frozen image into the internal memory of the main unit; it can store up to 420 images.
2. For the stored image, its fi le name is automatically named by the image code.
3. When storing images with one-key, you should always pay attention to the remaining frames within the internal memory
of the main unit to prevent invalid storage. After 420 images have been saved, delete it manually.
6.9 Image Management
6.9.1 Save the Image
1. In B, B / B, B / M, M mode, freeze the image.
2. Press key, a “Save” prompt appears on the lower right corner of the screen.
3. Press direction keys to select the image code need to be saved, such as choose “003”.
4. Press key, the current image is saved in the frame coded “003”. The saved image code is preceded with an asterisk “*”.
5. Press key to quit saving status and press key to return to real-time status.
Explanation: Images can be saved into the internal memory of the main unit; it can store up to 420 images.
6.9.2 Read the Image
1. In B, B / B, B / M, M mode, freeze the image.
2. Continuously press key twice, a “Read” prompt appears on the lower right corner of the screen.
3. Press direction keys to select the image code need to be read out, such as “003*”.
4. Press key to read out the image stored in the frame “003*”. “Img” character shown at the lower right corner of the
screen.
5. Press key to quit reading status and press key to return to real-time status.
Explanation: When reading images, choose the image code with “*”.
6.9.3 Delete the Image
1. In B, B / B, B / M, M mode, freeze the image, press key to enter saving or reading image status.
2. Press direction keys to select the image code to be deleted, such as “002*”.
3. Press key, the image stored in the main unit will be deleted, “*” will automatically disappear.
4. Repeat the steps 2 – 3 to delete other images.
5. Press key to return to real-time mode.
6.9.4 Review the Image
1. In B, B / B, B / M, M mode, freeze the image, press key to enter saving or reading image status.
2. Press key to review the images, the stored images will be automatically played by the fi xed time interval.
3. Press direction keys to select the previous or the next image to review.
4. Press key to return to frozen status.
5. Press key to return to real-time mode.
6.9.5 Transfer a Single Image to Workstation
1. In B, B / B, B / M, M mode, freeze the image, press key to enter saving or reading image status, such as “004*”.
2. Press key, a symbol “>>>>” prompt appears on the lower right corner of the screen. After the prompt disappear, the
image stored in frame “004*” is transferred to ultrasound workstation.
3. Press key to quit saving or reading image status.
4. Press key to return to real-time mode.
Note: The specifi c functions of ultrasound workstation, see Chapter Ten “Ultrasound Workstation Software Instructions”.
