USER MANUAL MAGIC 500 PLUS ULTRASOUND UNIT
T +49 7461 96 580 0 | F + 49 7461 96 580 90 | export@eickemeyer.com | www.eickemeyer.com
10.3.1 Preparation Before Use
1. In the MAGIC 500 PLUS preset interface, WiFi is set to “On”.
2. Connect to WLAN. Go to Settings of phone, tap WLAN, open WLAN, the phone will search and list the available WLAN.
3. In the available WLAN list, select MAGIC 500 PLUS network ID, such as “1712250”, connect to it.
4. After the connection is successful, tap the icon “ kx_station_v” to enter ultrasound workstation interface, the wireless
signal icon “ ” appears on the lower left corner of the MAGIC 500 PLUS screen. Then you can use the mobile ultrasound
workstation software.
Note:
1. You fi rst turn on the WiFi of MAGIC 500 PLUS and then set up the phone’s WLAN. After WLAN connection is successful, open
the ultrasound workstation software.
2. The WiFi network ID of MAGIC 500 PLUS is the default number displayed on the nameplate of MAGIC 500 PLUS, such as
“1712250”.
3. When the network is disconnected, the wireless signal icon on the MAGIC 500 PLUS screen disappears.
10.3.2 Start using mobile ultrasound workstation software
Mobile ultrasound workstation software kx_station_v includes image view, check list management, obstetric list management.
kx_station_v software consists of four function keys: Image View , Check List , OB and quit .
10.3.2.1 Image View
1. After the connection between MAGIC 500 PLUS and kx_station_v is successful, the lower left corner of MAGIC 500 PLUS
screen shows the wireless signal icon .
2. The images stored inside of MAGIC 500 PLUS will be transferred to the ultrasound workstation:
• Transfer a single image: Freeze the image, press key to enter saving or reading image status, such as choose
“004*”. Press key, a symbol “>>>>” prompt appears on lower right corner of the screen, after the prompt disappear,
the image stored in frame “004*” is transferred to ultrasound workstation.
• Batch images transfer: Freeze the image, press key to transfer all the stored images to the ultrasound workstation.
Note: When transferring single or multiple images to the ultrasound workstation with WiFi, if the image cannot be
transferred, the screen prompts “Poor network environment, please try again later!”. Wait until the network is good,
and press key to continue transferring the image.
• Press key to quit, then press key to return to real-time mode.
3. Tap Image View to browse received images.
4. Tap the icon in the lower right corner of the Image View interface, open the mobile album, fi nd the “image”, you can
browse the received images.
Explanation:
1. Tap the refresh icon on the lower right corner of the ultrasound workstation software, the received images can be
displayed correctly and be arranged according to the internal number of descending order stored in the MAGIC 500 PLUS.
2. Images are named according to system time. For example: DSC012_20171026135127.
Indicates the 12
th
image stored inside the MAGIC 500 PLUS at 13:51:27, Oct 26, 2017.
3. The stored bmp images are saved to your phone or pad folder.
View or delete the path: open Files / Local / Internal storage / kxStation “image” folder on your phone or pad.
For example: Local / Internal Storage / kxStation / image / DSC012_20171026135127.bmp
10.3.2.2 Check Lists Management
1. After the connection between MAGIC 500 PLUS and kx_station_v is successful, the lower left corner of MAGIC 500 PLUS
screen shows the wireless signal icon .
2. The check lists stored inside of MAGIC 500 PLUS will be transferred to the ultrasound workstation:
• In the B, B / B mode, freeze the desired image.
• Press direction keys to move the cursor to “Checklist”, press key to enter check list interface.
• Press key, a symbol “>>>” prompt appears at the upper right of the screen, after the prompt disappear, all the check
lists will be transferred to ultrasound workstation.
• Press key to exit check list interface and press key to return to real-time status.
