6 Setting
Page
27
/
52
The rotational speed (RPM) varies in different operating modes, as
shown in the table below
120 150 200 250 280
300 350 400 450 500
550 600 650
Torque (N·cm) in different operation modes, the torque value can be
set differently even in the same operation mode when the speed value
is set differently. See the table below for details.
0.5 0.8 1.0 1.5 1.8 2.0 2.2 2.5 3.0
3.2 3.5 4.0
There are 5 fixed values of reciprocating Angle in M0 reciprocating
mode, and the Angle cannot be changed., as shown in the table below.
Five sets of fixed values
1. Fwd angle 30°, Rev angle 150°
2. Fwd angle 150°, Rev angle 30°
3. Fwd angle 180°, Rev angle 30°
4. Fwd angle 210°, Rev angle 30°
5. Fwd angle 250°, Rev angle 30°
