Eighteeth UltraMint - Technical Data

9 Technical Data
Page 29 / 35
9. Technical Data
Manufacturer
Changzhou Sifary Medcial Technology Co.
Model
UltraMint
Box dimensions
395mm×230mm×90mm
Total weight
2.8kg
Power supply
~220-240V 50/60Hz
Main unit input
~25V 50/60Hz 1.3A
Output primary tip vibration
excursion
1μm-200μm
Output tip vibration frequency
25kHz~42kHz
Output half-excursion force
0.1N~2N
Output power
3W~20W
Power adapter fuse
T0.5AL250V
Main unit fuse
T1.6AL250V
Water pressure at inlet
0.1bar~5bar (0.01MPa~0.5MPa)
Electrical safety class
Class
Ⅱ
Applied part
B
Ingress protecting rating
Ordinary equipment (IPX0),
Foot pedal (IPX1)
AP / APG type equipment
None
Anti-defibrillation application part
None
Operating mode
Continuous operation
Operating conditions
Use: in enclosed spaces
Ambient temperature: 5°C ~ 40 °C
Relative humidity: <80%
Altitude max. 3000m
Transport and storage conditions
Ambient temperature: -20 °C ~ +55 °C
Relative humidity: 20% ~ 80 %
Atmospheric pressure: 70kPa ~ 106kPa
