10 EMC Tables
Page 31 / 35
Electrical fast
transients/bursts
IEC 61000-4-4
±2kV
100kHz repetition
frequency
±2kV
100kHz repetition
frequency
Mains power quality should be
that of a typical commercial or
hospital environment.
Surge
IEC 61000-4-5
Line to line:
±0.5kV, ±1kV
Line to earth:
±0.5kV, ±1kV,
±2kV
Line to line:
±0.5kV, ±1kV
Line to earth:
±0.5kV, ±1kV,
±2kV
Mains power quality should be
that of a typical commercial or
hospital environment.
Voltage dips
IEC 61000-4-11
Voltage
interruptions
IEC 61000-4-11
0% UT; 0.5 cycle
at 0°, 45°, 90°,
135°, 180°, 225°,
270°, and 315°
0% UT; 1 cycle and
70% UT; 25/30
cycles
sine phase at 0°
0% UT; 250/300
cycle
0% UT; 0.5 cycle
at 0°, 45°, 90°,
135°, 180°, 225°,
270°, and 315°
0% UT; 1 cycle
and 70% UT;
25/30 cycles
sine phase at 0°
0% UT; 250/300
cycle
Mains power quality should be
that of a typical commercial or
hospital environment. If the
user of devices require
continued operation during
power mains interruptions, it is
recommended that devices be
powered form an
uninterruptible power supply or
a battery
Rated Power
frequency
magnetic field
IEC 61000-4-8
30 A/m
50Hz or 60Hz
30 A/m
50Hz or 60Hz
Power frequency magnetic
field should be at levels
characteristic of a typical
location in a typical commercial
or hospital environment.
Note: UT: rated voltage(s); E.g. 25/30 cycles means 25 cycles at 50Hz or 30 cycles at 60Hz
Guidance and manufacturer’s declaration – electromagnetic immunity
The UltraMint is intended for use in the electromagnetic environment specified below. The
customer or the user of the UltraMint should assure that it is used in such an environment.
Immunity test
IEC 60601 test
level
Compliance level
Electromagnetic environment -
guidance
