6
Chapter 1 Introduction
Chapter 1 Introduction
1-1. Features
• 27.0″ wide format LCD
• Wide color gamut (Adobe
®
RGB coverage: 99%)
• Supports a resolution of 2560 × 1440.
• IPS panel with 178˚ horizontal and vertical viewing angles
• Frame synchronization mode supported (23.75 - 30.5Hz, 47.5 - 61.0Hz)
• 3 signal input terminals (DVI-D × 1, HDMI × 1, DisplayPort × 1)
- DisplayPort connector (applicable to 8 bit and 10 bit)
*1
- HDMI connector (applicable to 8 bit, 10 bit, and 12 bit)
*1,*2
Can handle PC signals in HDMI input
*1 Not applicable to audio signals.
*2 The maximum screen display is 10 bits.
• Color Mode function
Reproduces a color temperature, gamma, and gamut compliant with the following standard.
- Adobe
®
RGB / sRGB
• Stand with wide range of movement
The monitor can be adjusted to a position where it provides you with a comfortable and less tiring work environment.
(Tilt: up 35˚/down 5˚, Swivel: 344˚, Adjustable height: 141 mm (Tilt: 35°), 148 mm (Tilt: 0°))
• Supports portrait format
• The “ColorNavigator 6” Color Management Software enables you to calibrate monitor characteristics and
generate color proles
See “1-3. EIZO LCD Utility Disk” (page 9).
• Displays HDCP (High-bandwidth Digital Protection) protected contents.
Note
• This monitor supports portrait format. You can change the orientation of the Setting menu when using the monitor
screen in vertical display position. (see “Setting Orientation” (page 27))
• When using the monitor screen in a portrait position, the graphics board supporting portrait display is required. When
placing the monitor in a portrait position, the settings of your graphics board need to be changed. Refer to the User’s
Manual of the graphics board for details.
To Next Page
