Chapter 1Chapter Basic Adjustment / Setting
Chapter 1 Basic Adjustment / Setting
This chapter describes the basic functions that can be adjusted and set by pressing the buttons on the front
of the monitor.
1-1. Loading the Monitor Settings
Basic settings are made in advance at the factory.
It is possible to switch to the following preset settings that have been set in advance.
DisplayPort [LINE BY
LINE]
Basic settings for DisplayPort. The input signal is set to DisplayPort when this item is
selected.
Settings cannot be changed.
For information about the main default settings, see “4-1. Main Default Settings” (page 19).
SDI [SIMUL] Basic settings for SDI. The input signal is set to SDI 1 | SDI 2 when this item is selected.
Settings cannot be changed.
For information about the main default settings, see “4-1. Main Default Settings” (page 19).
HDMI [LINE BY LINE] Basic settings for HDMI. The input signal is set to HDMI when this item is selected.
Settings cannot be changed.
For information about the main default settings, see “4-1. Main Default Settings” (page 19).
DVI [2D] Basic settings for DVI. The input signal is set to DVI when this item is selected.
Settings cannot be changed.
For information about the main default settings, see “4-1. Main Default Settings” (page 19).
"User1" through
"User5"
You can save the current setting values and display status in the following items.
These items are not selectable unless they have been saved. For details, see “Saving
current settings to “User1” through “User5”” (page 5).
1.
Press (PRESET).
The preset menu is displayed.
2.
Press to select the item to load, and then press (ENTER).
The pre-made settings are loaded and the settings are changed.
Note
• The preset menu will disappear after about 10 seconds have elapsed if no operation is performed.
