Eizo DuraVision FDF2711W-IP Installation Manual

55
Chapter 4 Management of Network Cameras
4-2. Registering a Network Camera Manually
1.
Select “Camera Registration”.
A screen is displayed to show a list of camera registration information.
2.
Select a position where the camera is to be registered.
Place a check mark on the check box of the position number where the camera is to be registered.
3.
Select “Manual Registration” in the lower part of the screen.
The “Camera Information Settings” dialog box is displayed.

Eizo DuraVision FDF2711W-IP Specifications

General

Panel Type	IPS
Contrast Ratio	1000:1
Viewing Angle (H/V)	178°/178°
Connectivity/Video Inputs	HDMI, DisplayPort, DVI-D, VGA
IP Decoding	Yes
PoE++	Yes
Screen Size	27 inches
Resolution	1920 x 1080
Brightness	300 cd/m²
Color Depth	8-bit (16.77 million colors)
