Chapter 3 Setting Monitor
Chapter 3 Setting Monitor
3-1. Enabling / Disabling DDC/CI communication
This function allows you to enable / disable the DDC/CI communication (see “Chapter 7 Glossary” (page
42)).
Procedure
1. Choose “Monitor Settings” in the Setting menu, and press
.
2. Choose “DDC/CI” in the “Monitor Settings” menu, and press
.
The “DDC/CI” menu appears.
3. Select “On” or “Off” with or .
4. Press
to exit.
Note
• The DisplayPort input of this monitor does not support DDC/CI communication.
3-2. Locking Operation Buttons
This function allows you to lock the settings to prevent them being changed.
Procedure
1. Press
to turn off the monitor.
2. Hold down
while pressing to turn on the monitor.
The Lock / Unlock setting is toggled by performing the operation in step 2.
Note
• The following operations are available even if the buttons are locked:
- Turning on or off the monitor with the Power button
3-3. Setting Orientation
This function allows you to change the orientation of the Setting menu when using the monitor screen in
vertical display position.
Procedure
1. Choose “Monitor Settings” in the Setting menu, and press
.
2. Choose “Menu Settings” in the “Monitor Settings” menu, and press
.
3. Choose “Orientation” in the “Menu Settings” menu, and press
.
The “Orientation” menu appears.
4. Select “Landscape” or “Portrait” with or .
5. Press
to exit.
6. When selecting “Portrait”, turn the monitor screen 90˚ in clockwise direction.
Attention
• Be sure that the cables are correctly connected.
Note
• For using the monitor with “Portrait” position, the graphics board supporting portrait display is required. When
placing the monitor in a “Portrait” position, settings of your graphics board need to be changed. Refer to the
User’s Manual of the graphics board for details.
