Eizo FlexScan S2133-BK

39
Chapter 6 Reference
6-5. Specications
LCD Panel Size 21.3-inch (540 mm)
Type TFT color LCD, LED backlight
Surface treatment Anti-Glare Hard Coating
Viewing angles Horizontal 178˚, vertical 178˚ (CR≥10)
Dot Pitch 0.270 mm
Response Time Black-white-black: Approx. 20 ms
Gray-to-gray: Approx. 6 ms (Overdrive setting: Enhanced)
Horizontal Scan
Frequency
Analog 24 - 80 kHz
Digital DVI 31 - 76 kHz
DisplayPort 31 - 76 kHz
Vertical Scan
Frequency
Analog 49 - 76 Hz (non-interlace) (1600 × 1200: 59 - 61 Hz)
Digital DVI 59 - 61 Hz (non-interlace) (VGA TEXT: 69 - 71 Hz)
DisplayPort 59 - 61 Hz (non-interlace) (VGA TEXT: 69 - 71 Hz)
Resolution 1600 Dots × 1200 Lines
Max. Dot Clock Analog 162 MHz
Digital DVI 162 MHz
DisplayPort 162 MHz
Max. Display Color Approx. 16.77 million colors
Display Area (H × V) 432.0 mm (17.0 inch) × 324.0 mm (12.8 inch)
Power Supply 100 - 120 VAC ±10 %, 50 / 60 Hz 0.8 A
200 - 240 VAC ±10 %, 50 / 60 Hz 0.5 A
Power
Consumption
Screen Display On 45 W or less
Power saving mode 0.3 W or less (with no USB connections)
Power Off 0.3 W or less
Input Signal Connector D-Sub mini 15-pin
DVI-D connector (Applicable to HDCP)
DisplayPort (Standard V1.1a, applicable to HDCP)
Analog Input Signal (Sync) a) Separate, TTL, positive/negative
b) Composite, TTL, positive/negative
Analog Input Signal (Video) Analog, Positive (0.7 Vp-p / 75 Ω)
Digital Signal (DVI) Transmission System TMDS (Single Link)
Plug & Play Analog / Digital (DVI-D) : VESA DDC 2B / EDID structure 1.3
Digital (DisplayPort) : VESA DisplayPort / EDID structure 1.4
Dimensions
(Width) ×
(Height) ×
(Depth)
Main unit
465 mm (18.3 inch) × 453 - 535 mm (17.8 inch - 21.1 inch) × 208.5 mm
(8.2 inch)
Main unit (without
stand)
465 mm (18.3 inch) × 361 mm (14.2 inch) × 64 mm (2.52 inch)
Mass Main unit Approx. 8.6 kg (19 lbs.)
Main unit (without
stand)
Approx. 5.6 kg (12.3 lbs.)
Movable range Tilt: 40˚ Up, 0˚ Down
Swivel: 70˚ Right, 70˚ Left
Adjustable height: 82 mm (3.23 inch)
Rotation: 90˚ (Clockwise)
