- 17 -

STEP 7

CONNECTING THE ANTENNAS

Connect the Bluetooth and Wi-Fi antennas with the PS5 PCB. Make

sure to select the correct connector for each antenna.

STEP 7

BLACK WIRE

WHITE WIRE - SHORTER

BLUE WIRE

WHITE WIRE - LONGER
