EKOM DK50 2V/50 - 8. PRODUCT FUNCTION

PRODUCT DESCRIPTION
NP-DK50 2V 50, 2x2V 110-A-5_06-2020-MD 12 06/2020
Type
Use
Filtration level /µm/
Pressure
regulator
Article no.
FS 32FR
DK50 2V/50
5
yes
447000001-089
FS 32M
5 + 0,3
no
447000001-090
FS 32MR
5 + 0,3
yes
447000001-091
FS 32S
5+ 0,3 + 0,01
no
447000001-092
FS 32SR
5+ 0,3 + 0,01
yes
447000001-093
FS 33S
DK50 2V/50/M
0,3 + 0,01
no
447000001-094
FS 33SR
0,3 + 0,01
yes
447000001-095
FS 33SR2
0,01
yes
447000001-133
FS 34FR
DK50 2x2V/110
5
yes
447000001-097
FS 34M
5+ 0,3
no
447000001-098
FS 34MR
5 + 0,3
yes
447000001-099
FS 34S
5+ 0,3 + 0,01
no
447000001-100
FS 34SR
5+ 0,3 + 0,01
yes
447000001-101
FS 35S
DK50
2x2V/110/M
0,3 + 0,01
no
447000001-102
FS 35SR
0,3 + 0,01
yes
447000001-103
FS 35SR2
0,01
yes
447000001-132
Condensation and filtration unit
The compressor can be equipped with a condensation and filtration unit. The unit is used to cool the
compressed air from the air tank in the cooler, to capture condensate in the filter, to drain condensate
automatically from the pneumatic system and to filter the compressed air.
Type
Use
Filtration level /µm/
Pressure
regulator
Article no.
KJF-2
DK50 2x2V/110
5
no
450001021-001
Equipotential bonding socket
The socket provides protective bonding. (Fig. 11)
Type
Use
Name
Article no.
POAG-KBT6-EC
DK50 2V/50S
DK50 2V/50S/M
DK50 2x2V/110
DK50 2x2V/110/M
Mains plug
connector
033400075-000
FLEXI-S/POAG-HK6
Conductor (1 m)
034110083-000
8. PRODUCT FUNCTION
8.1. Compressor
Fig. 1 Air pump (1) sucks the atmospheric air in through the inlet filter (8) and compresses it through
the non-return valve (3) into the air tank (2) from which the device draws in the compressed air. If
the pressure in the air tank drops to the switch-on pressure, the pressure switch (4) switches the
compressor on and the compressor compresses the air into the air tank until it reaches the switch-
off pressure, when the compressor switches off. The pressure hose is vented through the solenoid
relief valve (13) once the compressor pump is switched off. The safety valve (5) prevents the
pressure in the air tank from rising above the maximum allowed value. The drain valve (7) drains the
condensate from the air tank. Compressed, oil-free filtered air is stored in the air tank ready for use.
Condensate must be drained from the air tank at regular intervals (see chapter 17.1).
