Menu
Title
Description
Available Settings
Default
35
TX BW
Transmission filter selection for FM,
AM and SSB mode.
50Hz - 4000Hz
100Hz - 2700Hz
100Hz - 3000Hz
100Hz - 3500Hz
100Hz - 4000Hz
200Hz - 2700Hz
200Hz - 3000Hz
200Hz - 3500Hz
200Hz - 4000Hz
300Hz - 2700Hz
300Hz - 3000Hz
300Hz - 3500Hz
300Hz - 4000Hz
100Hz - 2700Hz
36
MIC GAIN
Microphone Gain
±12dB in step of 0.5dB
0dB
37
CW IN
CW transmission input selection.
The Key+DTR option appears only
when the USB is connected and is
automatically disabled when the USB
is disconnected, re-setting the
selection to Key.
This is done to avoid unwanted TX
operations due to USB setup
transient phases.
Key, Paddle, Key+DTR,
Paddle+DTR
Key
38
CW DELAY
PTT release delay in CW
0 to 1000ms
240ms
39
CW KEY
Selects where the key is connected on
the key/paddle jack
TIP or RING
TIP
40
CW TIP
Selects the dot or dash on the tip of
the key/paddle jack
DOT or DASH
DASH
41
CW IAMBIC
Sets the iambic mode
A or B
A
42
CW RX WPM
CW characters decoding speed
5 to 90 words per minute
12
43
TX RX TH
CW threshold for a tone recognition
AUTO or from 1 to 10
AUTO
44
CW DECODE
Enables/disables the automatic CW
decoding
OFF or ON
OFF
45
CW TX WPM
CW transmission speed
5 to 90 words per minute
10
46
CW MSG
CW message selection
Msg 1 to Msg 10
Msg 1
47
TX VIEW
Selects the default parameter to be
displayed during a transmission
Frequency, forward power,
reflected power, SWR
Forward power
48
UP/DOWN ACC
MIC UP / DOWN acceleration of the
microphone buttons
1, 2, 3
2
49
TUNE TIME
Antenna tuning mode timeout. Active
only if the selected transmission
output is the antenna. Not active in
service mode
3 to 120 seconds
10s
50
ATT ON TX
Attenuation in transmission mode
OFF or ON
OFF
51
NOISE TH
Sets the noise gate threshold.
Available only if TXIN is set to MIC
OFF,1,2,... 10
2
52
COMP GAIN
Sets dynamic compression gain.
Available only if TXIN is set to MIC
OFF,1,2,... 10
7
53
TX FM DEV
Transmission FM deviation
2.5kHz, 5kHz
2.5kHz
54
PTT
PTT control
PTT, PTT+RTS
PTT
