34
Menu
Title
Description
Available Settings
Default
55
TUNE POWER
Sets the TUNE power
0.3W, 0.5W, 1W, 1.2W,
1.5W, 2W, 3W, 4W, 5W or
max available
5W
56
TUNE PTT
Sets the PTT OUT behavior when in
tune mode
YES or NO
YES
57
PTT DELAY
PTT OUT anticipation and delay in
SSB, AM and FM
0 to 1000ms
0ms
58
PTT ON CW
Sets the microphone PTT key
behavior when CW mode is selected
CW message preparation,
PTT out assertion
CW message
preparation
GENERAL SETTINGS MENU
60
FR OFFSET
Enables/disables the frequency offset
for the visualization
OFF or ON
OFF
61
OFS VALUE
Frequency offset value for the
visualization
+/- 99.999999999 GHz.
See Frequency
visualization offset
menu
0Hz
62
F4
Selects the F4 key function when a
long pressure is applied
None / Send CW Message /
Split / Main encoder tuning
lock / Switch between CW
and CWR
Send CW
Message
63
F5
Selects the F5 key function when a
long pressure is applied
None / Send CW Message /
Split / Main encoder tuning
lock / Switch between CW
and CWR
Main encoder
tuning lock
70
CAT BAUD
CAT serial port baud rate
9600, 38400, 57600,
115200
38400
71
HOLD TIME
Hold time to detect a long pressure
From 500 to 2500ms
1000ms
72
REPT TIME
Repetition time when a key is pressed
From 100 to 1500ms
600ms
73
TX BACKLIGHT
ON/OFF
Activates backlight when changing
operating mode (Stand Alone Rx,
Remote Rx, Stand Alone CW Tx,
Remote Tx)
YES or NO
YES
SERVICE MENU
80
SERVICE
Enables Service mode
ON or OFF
OFF
81
DEFAULT
Restores default parameters
YES or NO
NO
82
UI UPDATE
If Service mode is active, enables the
firmware update mode
YES or NO
NO
83
VIEW SN
Displays the FDM-DUO serial number
Parts of the SN
First part
84
VIEW FW
Displays the FDM-DUO firmware
versions
Firmware
UI
85
CLK ADJ
Sets the internal clock correction
value. It is used to have a fine
frequency setting.
In case of “Ref In” utilization, this
parameter is not relevant.
±50000 dots (not Hz)
-
