9 Technical Specifications
ELAD FDM-DUO TECHNICAL SPECIFICATIONS
GENERAL
USB 2.0 Ports (Peripheral Control)
3 (RX, TX, CAT)
Master Clock Frequency
122.88 MHz (Rx), 368.64 MHz (Tx)
Master Clock Phase Noise
-136 dBc @ 100 kHz, -130 dBc @ 10 kHz
10 MHz Reference Clock Stability
2.5 ppm TCXO within temperature range 0°C ÷ 40°C (32°F ÷ 104°F)
Typical Stability within temperature range 15°C ÷ 35°C (59°F ÷ 95°F) 0.1 ppm i.e. 1Hz @ 10 MHz
Frequency Resolution
1 Hz min.
Antenna Connectors / Impedance
2x SO-239 / 50 Ohm
RF-OUT Connector / Impedance
SMA female / 50 Ohm
Power Supply Requirements
13.8 Vdc ± 10%
Current Drain (Rx / Tx 5 W)
<500 mA @ 13.8 V / <2.2 A @ 13.8 V
Dimensions (W x D x H)
180 mm (7.00") x 155 mm (6.10") x 70 mm (2.75") including knob and connectors
180 mm (7.00") x 130 mm (5.10") x 70 mm (2.75") enclosure only
Weight (approximate)
1.2 Kg (2.4 lb)
Operating Temperature Range
0°C ÷ 40°C (32°F ÷ 104°F)
Stand Alone Mode
RECEIVER
Modes
CW, USB, LSB, AM, FM
ADC Sampling Rate / Resolution
122.88 MHz @ 16 bits
Wideband Frequency Coverage
10 kHz ÷ 54 MHz
IQ Channel Bandwidth
192 kHz (24 bits)
Attenuator
12 dB
Spurious Response
>105 dBfs @ 0 dB attenuation
DDC Image Rejection Ratio
>100 dB
Receive Low Pass Filters Bandwidth
SSB: 300 Hz, 600 Hz, 1 kHz, 1.6 kHz ÷ 3.1 kHz (Step 100 Hz), 4 kHz, 5 kHz, 6 kHz
AM: 2.5 kHz ÷ 6 kHz (Step 500 Hz)
CW: 100 Hz & DR
(1)
Level 1 ÷ 4, 100 Hz, 300 Hz, 500 Hz, 1kHz, 1.5 kHz, 2.6 kHz
FM: Voice Narrow, Voice Wide, Data
Headphones Connector / Impedance
3.5 mm Stereo Jack / 8 Ohm
AUX OUT Connector / Impedance
3.5 mm Stereo Jack / 8 Ohm
TRANSMITTER
Modes
CW, USB, LSB, AM, FM
TX DAC Sampling Rate & Resolution
368.64 MHz @ 16 bits
RF Output Power
5 W Nominal, Adj. Steps: 0.3 W, 0.5 W, 1.0 W, 1.2 W, 1.5 W, 2.0 W, 3.0 W, 4.0 W, 5.0 W, MAX
Amateur Band Coverage at Rated Power Output
160 m ÷ 6 m
Low Pass PA Filter Bands
160 m ÷ 6 m Ham bands only
RF-OUT Output Power
-2 dBm Typical; 0 dBm Max
RF-OUT Frequency Coverage
100 kHz ÷ 165 MHz
Modulation System
IQ Digital
Maximum FM Deviation
5 kHz
Carrier Suppression / Unwanted Sideband Suppression
>80 dBc Typical / >80 dBc Typical
Harmonic Radiation 1.8 - 50 MHz Amateur Bands
>60 dBc
3
rd
Order IMD
160 m ÷ 10 m: >30 dB @ 5 W PEP; 6 m: >25 @ 5 W PEP
Transmit Filters Bandwidth
SSB, AM: 300 Hz ÷ 2700 Hz Band Pass up to 50 Hz ÷ 4000 Hz Band Pass
FM: 2500 Hz or 5000 Hz Low Pass
Microphone Connectors
RJ45 ICOM Compatible
Microphone Impedance
600 Ohm Nominal (200 ÷ 10 kOhm)
PTT-OUT Connector
3.5 mm Stereo Jack, NPN Open Collector Output 20 V Max / 200 mA
KEY-PAD Connector
3.5 mm Stereo Jack
PC Based Mode
(ELAD FDM-SW2 Software)
RECEIVER
Modes
CW, CW SH+, CW SH-, CW Narrow Band, USB, LSB, AM, FM, WB FM (Stereo + RDS), SYNC AM, DSB, RTTY,
ECSS, DRM
IQ DDC Sampling Rate / Resolution
1 Channel (Slice) @ 32 bits: 192 kHz, 384 kHz, 768 kHz, 1536 kHz, 3072 kHz
1 Channel (Slice) @ 16 bits: 6144 kHz
2 Channels (Slices) @ 32 bits: 192 kHz, 384 kHz
Simultaneous Receivers
4 with 1 Channel (Slice) DDC, 8 with 2 Channels (Slices) DDC
Software Defined Filters
Double IF Notch Filters, Continuous Variable Band Filter
Advanced DSP Features
Noise Blanker, Adaptive Noise Reducer, Adaptive Auto Notch, AGC
Main Software Features
Recording and playback of IF and audio data stream, EIBI database support, Dx-Cluster spot visualization
(Internet connection required), built in CAT protocol and Omni-Rig Server, double output channel (for VAC),
support for external down-converter, WoodBox Tmate and Tmate2 compatibility
Software Visualization
Input Data (Spectrum + Waterfall), IF Data (Spectrum + Waterfall), Audio Data (Spectrum + Waterfall)
TRANSMITTER
Modes
CW, USB, LSB, AM, FM, IQ
Transmit Bandwidth
CW, USB, LSB, AM: default 300 ÷ 2700 Hz, up to 50 ÷ 4000 Hz
FM: 2500 or 5000 Hz Low Pass
Advanced DSP Features
Equalizer, VOX, Audio Compressor, Overshoot Control (CESSB Algorithm), Level Limiter
Main Software Features
Playback of audio files (up to 4 presets)
Software Visualization
Waveform Monitor (Input Audio, Equalizer Output, Compressor Output, Filter Output, Overshoot Controller
Output, Modulator Output, Limiter Output)
(1) Digital Resonator
All stated specifications and other product information provided in this document are subject to change without notice or obligation.
