4. PRESENTATION ELBO CONTROLLI srl
Preset E236+
6
4. PRESENTATION
First, we would like to take this opportunity to thank you for your purchase of ELBO CONTROLLI’s E236+
Presetters. You will certainly have great satisfaction with the decision you have made, and you will increase
the productivity of your NC machines.
The E236+ Presetters have been manufactured in compliance with ergonomics and simplicity principles
and offer outstanding technological solutions. The mechanical systems, electronics and software deal with
tool measurement and pre-adjustment. The vision system, designed by ELBO CONTROLLI, is used to
collect measurement data automatically.
The good value for money and the precision of measurements make the E236+ one of a kind.
Technical Features
MECHANICS
× Measuring range: diameter max 260 mm (radius 130 mm); height max 360 mm
× Base and column made of natural granite
× ISO/BT/HSK/VDI... etc. interchangeable rotating spindle-holder (to be specified)
× 4 re-circulating ball bearing linear slides
× Manual mechanical braking of the interchangeable spindle-holder rotation
× Manual axes movement
× External 24Vcc power supply
× Overall dimensions: L = 570 mm, H = 793 mm, D = 408 mm Net weight: 45 kg
ELECTRONICS - OPTICS
× Vision system for tool measuring
× ELBO CONTROLLI NIKKEN linear transducers in optical glass type SLIDE 371
× Axes resolution X = 1 μm, Z = 1 μm.
× C-MOS sensor framed image area 5 x 5 mm
× 20X magnification.
× Telecentric lens and LED illuminator
× TFT colour LCD 7” LED backlight point matrix graphic display (86 x 150 mm image size)
× Full touch screen for all Presetter operation
× ELBO CONTROLLI NIKKEN Firmware
× Data storage on flash memory
× Electronics driver based on RISC 32 BIT processor and integrated vision system
SOFTWARE
× 9 numerical machine origin management
× 9 numerical tool tables management, each of them composed of 99 tools
× Tool corrector specific storage of: T, Lx, Lz, insert radius
× Intuitive icons and menu-based software
× Display radius/diameter, mm/inch, ABS/INC
× Measurement capability by full-screen auto-targeting
× X axis and Z axis focusing control bars
× Radius and angle automatic computing cycle
× Td236+ (Tool Data 236+) to manage backup and restore functions, machine origins and tool table. Connection
to the PC with an USB port and electronic Bios upgrade
OPTIONS
× Interchangeable rotating spindle ISO/BT/HSK/VDI…etc. additional
× Mini-label printer
× Support table
