13
AEROTOP T..C
5 Contactor electric heating element
6 Main incoming supply 3*400V
7 Fan fuse / control fuse (F3)
8 Soft-starter and rotary current relay
Electrical Connection
Switch box
1 2 3 4
5 ....6 7 8
Legenda:
1 Terminal strip consumer, power
station blockage
2 Terminal strip Fan Contactor / oil
sump heater
3 Heat pump controller
LOGON B WP61
4 Mains supply plug:
Mains connector phase AC 230 V
Main connector neutral connector
