Technical Data
AEROTOP T20-T35
1) Min: t max= 10 K, with PHW-preparation tmax = 5 K. (V' [l/h]= Qh[kW]/(4.18*t[K]*ρ[kg/l])*3600).
2) At maximum fan rotational speed.
3) Measuring according to DIN ISO 9614-2. Sound power level is a property of the source of noise and therefore dependent on the
distance; it describes the totality of the sound power of the corresponding source radiating in all directions. Information to deter-
mine the noise level see planning documents.
4) With Hl and HO Hoods
41
Heat pump type AEROTOP T T20 T26 T32 T35
Heating operation For A2/W35
Heating Capacity Qh kW
18.9 24.4 30.2 33.4
Power input Pel kW
5.8 7.4 8.8 9.2
Performance number EN14511 COP -
3.2 3.3 3.4 3.6
Condenser Scroll hermetically
Maximum current consumption lmax A
16 22 27 25
Start-up current with smooth starter VSA A
40 55 67.5 62.5
Current intensity with blocked rotor LRA A
99 123 127 167
Current connection V-f-Hz
400-3-50
Fuse WP A/T
32 40 40 40
Condenser, heater side Material: Chrome steel AISI 316, 1.4401
Hydraulic connections IG Zoll
1¼” 1¼” 1¼” 1¼”
Water content incl. connection hoses AEROTOP T l
4.9 4.9 5.7 5.7
Volume stream heating operation nom/min
1)
l/h
3700/1714 5850/2259 6280/2803 7300/2964
Pressure loss heating operation kPa
14.9/4.5 32.9/7.7 36.1/6.4 46.7/7
Max working pressure
p bar
10 10 10 10
Evaporator/fan
Volume stream m
3
/h
7'300 8'200 10000
11000
Available pressure
2)
Pa
155 75 255
180
Power consumption fan P kW
0.530 0.700 0.500
0.650
Maximum current consumption fan lmax. A
1.8 1.8 2.8 2.8
Coolant -
R407C
Coolant filling AEROTOP T kg
6 7.4 9.2 9.2
Coolant circuit oil - Ester oil
Oil quantity l
4.1 4.1 4.1 4.1
Weight heat pump
AEROTOP T kg
375 392 460 468
Sound Level
3)
Outdoor installation
Standard configuration with Hoods
4)
Lwa dB(A)
66.0 70.0 67.0 70.0
Sound Level
3)
Indoor setup
Sound power level On suction
Lwa dB(A)
65.0 67.0 66.0 70.0
On exhaust
Lwa dB(A)
59.0 61.0 64.0 67.0
Inside
Lwa dB(A)
59.0 59.0 63.0 68.0
